ZJ RD-80250

Radial Arm Drill RD-80250 Title: Radial Arm Drill RD-80250 SKU: 138605 Model: RD-80250 Year: 2014 Condition: Used S/N: ZT1400011N GeneralType:Radial Arm Drill Bore Diameter:3.15" Arm Travel:39.37" Morse Taper:MT#6 Table Size:39.4" x 31.5" x 22" ElectricalHorsepower:10hp Additional DataDiameter of Column:21.65" Max drilling diameter: 80 mm // 3.15 in. Distance between spindle axis and column: 500 - 2500 mm // 19.68 - 98.43 in. Spindle travel: 450 mm // 17.72 in. Range of spindle speed: 16 - 1250 rpm Number of spindle speed: 16 steps Range of spindle feeds: 0.04 - 3.2 mm Spindle feed step: 16 steps Horizontal movement distance of spindle box (cross arm): 2000 mm // 78.74 in. Radial lift distance: 1000 mm // 39.37 in.
