Volvo EC 300

We have all the parts for the machinery:ROCK BUCKET/SKELETON BUCKET /LOOSENING BUCKET/CLEANING BUCKET TILT BUCKET/DITCH BUCKET/BUCKET CLAMP/CLAMSHELL BUCKET/ROTARY SCREEN/CRUSHER BUCKET/RUSHER BUCKET CRUSHING AND SCREENING BUCKET/RAKE/RIPPER/THUMB CLIP/COMPACTION WHEEL Business hours:24 hours, holidays and Sundays Contact: Lily Whatsapp: +86 13696501072 Mobile:+86 17756597429 Wechat:17756597429 Packaging Details 1. Flat frame is more suitable for large construction equipment without disassembly. 2. Containers are the cheapest and fastest. 3. Bulk carriers are more suitable for large construction equipment. 4. Ro-ro shipment is fast and suitable for all kinds of machines. You can choose any mode of transportation according to your needs.

Volvo EC300DL Excavator Parameter configuration specification Power: Traditional power Joint ventures/imports Bucket backhoe Tonnage (tons) 30 The working weight of the whole machine (kg) is 30040 Bucket capacity (m³) 1.4 Boom length (mm) 6200 Stick length (mm) 2550 performance Rotational speed (rpm) 10.7 Rotational torque (Nm) 110.9 Travel speed (km/h) 3.4/5.4 Bucket digging force (kN) 186 Stick digging force (kN) 161 Maximum traction (kN) 247 dynamical system Engine model D7E Rated power (kw/rpm) 170/1800 Maximum torque (N.m) 1080/1350 Displacement (L) 7.1 Number of cylinders (pcs) 6 Bore × stroke (mm) 108X130 Hydraulic system Main pump maximum flow rate (l/min) 2 x 263 Pilot pump flow rate (L/min) 3.9 Working hydraulic oil circuit (Mpa) 33.3/36.3 Walking Hydraulic Circuit (Mpa) 36.3 Slewing hydraulic circuit (Mpa) 27.9 Boom cylinder - number × bore × stroke (mm) 2×140 x 1480 Bucket cylinder - number × bore × stroke (mm) 1×150 x 1745 Bucket cylinder - number × bore × stroke (mm) 1×140 x 1140 Oil capacity Fuel tank (L) 470 Hydraulic Tank (L) 195 Hydraulic system (L) 400 Engine oil change volume (L) 32 Coolant (L) 41 Body size Total length of transport (mm) 10640 Total width of transport (mm) 3190 Cab total height (mm) 3090 Boarding width (mm) 2890 Track grounding length (mm) 4015 Total track length (mm) 4870 Track shoe width (mm) 600 Track gauge (mm) 2590 Minimum ground clearance (mm) 480 Counterweight ground clearance (mm) 1135 Number of support wheels (unilateral) (pieces) 9 Number of support wheels (one side) (pcs) 2 Number of track shoes (single side) (pcs) 50 Scope of work Maximum digging radius (mm) 10190 The maximum excavation radius of the stopping surface (mm) is 9980 Maximum digging depth (mm) 6850 Maximum digging height (mm) 9660 Maximum unloading height (mm) 6670 Maximum vertical digging depth (mm) 5730
